| Parameter |
Details |
| Material |
High-quality MS (Mild Steel) / High Tensile Steel |
| Outer Tube Diameter |
50mm (Customizable) |
| Inner Tube Diameter |
40mm (Customizable) |
| Sizes |
2x2 Mtr / 2x3 Mtr / 3x3 Mtr |
| Height Adjustment Range |
1m to 5m (Customized as per requirement) |
| Load Capacity |
1.5 – 4 Tons (Varies based on tube thickness & material strength) |
| Prop Nut Type |
Heavy-duty Cast Iron / Forged Steel Nut |
| Base Plate Size |
150mm × 150mm / 180mm × 180mm (Customizable) |
| Base Plate Thickness |
5mm / 6mm / 8mm |
| Top Plate Size |
150mm × 150mm / 180mm × 180mm |
| Top Plate Thickness |
5mm / 6mm |
| Pin Type |
Solid Pin / Snap Lock Pin for height adjustment |
| Finish Options |
Painted / Electro-Galvanized / Hot Dip Galvanized (HDG) |
| Weight |
Varies as per size and thickness |
| Welding Type |
CO2/MIG Welding for high strength & durability |
| Standards |
IS 1161, EN 10219, BS 1139 |
