| Parameter |
Details |
| Material |
High-quality Mild Steel (MS) / Galvanized Steel |
| Type |
Spigot Connector / Joint Pin |
| Application |
Used for vertical joining of scaffold tubes and Cuplock standards |
| Outer Diameter |
38mm / 40mm / 42mm (Customizable) |
| Length Options |
200mm / 225mm / 250mm / 300mm |
| Thickness |
3.0mm / 3.2mm / 4.0mm |
| Weight |
0.6 kg – 1.2 kg (Varies as per size & thickness) |
| Locking Mechanism |
With or Without Locking Pin |
| Finish Options |
Hot Dip Galvanized (HDG) / Painted / Electroplated |
| Load Capacity |
Up to 15kN (Depending on size & material) |
| Standards |
BS 1139, EN 12811, IS 1161 |
