| Parameter |
Details |
| Material |
High-quality MS (Mild Steel) / High Tensile Steel |
| Tube Diameter |
30mm / 32mm (Outer Diameter) |
| Thread Type |
Roll Thread / Cut Thread |
| Available Length |
350 mm / 450 mm / 600 mm (Customizable) |
| Base Plate Size |
100mm × 100mm / 150mm × 150mm (Customizable) |
| Base Plate Thickness |
5mm / 6mm / 8mm (Customizable) |
| Jack Nut Type |
Heavy-duty Cast Iron / Forged Steel Nut |
| Jack Nut Weight |
0.75kg – 1.2kg (Varies as per size) |
| Pin Diameter |
16mm / 18mm (Customizable) |
| Height Adjustment Range |
Up to 450mm (Varies based on project requirement) |
| Load Capacity |
3 – 5 Tons (Depending on size & material strength) |
| Finish Options |
Painted / Electro-Galvanized / Hot Dip Galvanized (HDG) |
| Weight |
Varies as per size and thickness |
| Welding Type |
CO2/MIG Welding for high strength & durability |
| Standards |
IS 1161, EN 10219, BS 1139 |
