| Parameter |
Details |
| Material |
High-quality Forged Steel / Mild Steel |
| Type |
Swivel Coupler (360° Rotation) / Fixed Coupler (90° Connection) |
| Tube Compatibility |
40mm to 50mm OD (Customizable for different scaffolding tubes) |
| Bolt Size |
12mm / 14mm / 16mm T-bolt with nut |
| Nut Type |
Heavy-duty hex nut |
| Weight |
0.8 kg – 1.2 kg (Depending on size & thickness) |
| Finish Options |
Electro-Galvanized / Hot Dip Galvanized (HDG) / Painted |
| Welding Type |
CO2/MIG Welding for durability |
| Load Capacity |
15kN – 20kN (Depending on size and standard) |
| Standards |
BS 1139, EN 74, IS 2750 |
